Fiberglass Direct Roving : Precision Reinforcement For Diverse Composite Applications
Fiberglass Direct Roving is a high-performance reinforcement material engineered for structural composites requiring exceptional strength, corrosion resistance, and process versatility. Composed of continuous E-glass filaments with a silane-based sizing, it ensures superior adhesion to resins like polyester, vinyl ester, and epoxy. Designed for filament winding, pultrusion, and weaving, this product delivers consistent fiber alignment and minimal fuzz, making it ideal for marine, energy, and industrial applications where durability and precision are critical.
Step | Description |
|---|---|
Fiber Formation | Molten glass is drawn into continuous filaments (13–30 microns) through bushings. |
Sizing Application | Filaments are coated with a silane-based sizing agent to enhance resin compatibility. |
Direct Roving | Untwisted fiber bundles are wound into roving packages using automated systems. |
Quality Control | Parameters like tex (200–9,600), tensile strength (≥3,000 MPa), and uniformity are verified. |
Packaging | Wound rovings are stored on pallets or in moisture-proof cartons for transport. |
Storage: Maintain dry, cool conditions (15–35°C) with humidity <65% to prevent fiber degradation.
Chemical Resistance: Compatible with polyester, epoxy, and vinyl ester resins; avoid contact with strong acids or solvents.
Handling: Wear PPE (gloves, goggles) to prevent fiber irritation; use sharp cutting tools to minimize fraying.
Temperature Limits: Operational range: -50°C to 150°C; avoid prolonged exposure to >180°C unless specified.
Parameter | Standard DR | High-Tex DR |
|---|---|---|
Tex Range | 200–4,800 | 6,000–9,600 |
Fiber Diameter | 13–30 microns | 13–30 microns |
Tensile Strength | ≥3,000 MPa (longitudinal) | ≥3,500 MPa (longitudinal) |
Linear Density | 200–9,600 tex | 6,000–9,600 tex |
Flammability | Self-extinguishing (UL94 V-0) | Self-extinguishing (UL94 V-0) |
Certifications | ISO 9001, REACH, RoHS | ISO 9001, REACH, RoHS |
Marine Engineering: Hulls, decks, and offshore platforms for saltwater corrosion resistance.
Energy Systems: Wind turbine blades, oil & gas pipelines, and geothermal equipment.
Automotive: Structural components (chassis, panels) and lightweight interiors.
Construction: Reinforced concrete panels, FRP grating, and architectural facades.
Industrial Machinery: Heavy-duty gears, pump shafts, and wear-resistant coatings.
Electronics: Circuit board enclosures and EMI-shielded housings.
|
|
